MEIYUAN Aluminum foil ceramic fiber board is made through automatic vacuum forming process. Compared to the traditional production process,we brought in one new full Automatic production line for board. 24 hours continuously working, quickly drying.
Products Details
Product Introduction:
MEIYUAN Aluminum foil ceramic fiber board is made through automatic vacuum forming process. Compared to the traditional production process,we brought in one new full Automatic production line for board. 24 hours continuously working, quickly drying. Ceramic fiber board enjoys higher compressive strength, tidy surface and precise size, which is easy for installation. The alumina foil is qualified with Europe standard, one-off adhesive and has good bond effect. One side, two sides and six sides aluminum foil are available.
Characteristics:
Resistance to high temperature;
Low thermal conductivity;
Resistance to thermal shock;
Excellent corrosion resistance;
Low shot content ;
Low heat storage;
High compressive strength;
Good sound absorption;
Excellent wind-erosion resistance, long service life;
Excellent thermal stability and thermal shock resistance;
Easily molded or cut, easy to install;
Accurate sizes and good flatness...
Application:
Industrial heat shields & thermal barriers
Industrial combustion chamber construction
Domestic appliance & light-duty industrial combustion chamber construction
refractory lining
Molten metal trough covers
Hot gas duct linings
Expansion joints
Insulating backup to dense refractory materials
Insulating backup to brick & castable
Furnace hot face lining in ceramic kiln, box furnace & petrochemical furnace
Use in industrial heat processing equipment
Rigid high-temperature gaskets & seals
High-temperature baffles & muffles
Flue & chimney linings in furnaces & kilns
Technical data and specification
| MEIYUAN ceramic fiber board | ||||||
| Specification temperature | 1050COM | 1260STD | 1260 HP | 1400 | 1430HZ | |
| Working Temp | 950℃ | 1050℃ | 1100℃ | 1200℃ | 1350℃ | |
| Color | Pure white | |||||
| Permanent Linear Change on Heating(%) (24h,density128 kg/m3) | ≤-4 (950℃) | ≤-3 (1050℃) | ≤-3 (1100℃) | ≤-3 (1200℃) | ≤-3 (1350℃) | |
| Rate of thermal conductivity(W/n.k)(Density 128 kg/m3) | 0.13(600 C) 0.20(800 C) | 0.13(800 C) 0.19(1000C) | 0.13(800 C) 0.19(1000C) | 0.12(600C) 0.20(1000C) | 0.16(600C) 0.20(1000C) | |
| Chemical Composition (%) | ||||||
| Al2O3 | 37 | 45-46 | 47-49 | 52-55 | 39-40 | |
| Al2O3+SiO2 | 96 | 97 | 99 | 99 | - | |
| ZrO2 | - | - | - | 5 | 15-17 | |
| Al2O3+SiO2+ZrO2 | - | - | - | - | ≥99 | |
| Fe2O3 | ≤1.0 | ≤0.8 | ≤0.2 | ≤0.2 | ≤0.2 | |
| Na2O+K2O | ≤0.8 | ≤0.5 | ≤0.2 | ≤0.2 | ≤0.2 | |
| specification | ||||||
| Thickness (mm) | 20/25/50 | 80/100 | ||||
| Density (kg/m3) | 280/300/320/350 | 280/300/320 | ||||
| Size (mm) | 1200*1000 or customized size | |||||
| Package | Carton box or pallet | |||||
Why choose us?
1. Self owned raw material base, material inspection before entering factory, computer-controlled ingredient proportion system, strictly control raw material purity. therefore, manufactured ceramic fiber board’s shot content is lower than similar products.
2. Continuously operating automatic production line offers product stable quality , which size is precise , high tensile strength.
3. Automatic temperature control system can complete deep drying within 2 hours., thus the high compressive strength and high rupture strength.
4. Manufacture ceramic fiber board with thickness varies from 25mm to 100mm.
5. Aluminum foil is qualified with ASTM fireproof standard.
6. One side, two sides and six sides aluminum foil are available.
