1260STD Ceramic Fiber Board

MEIYUAN 1260STD ceramic fiber board is a board made by an automatic vacuum forming process. Compared with the traditional production process, we have introduced a new fully automatic production line.

Inquire Now Next Product

Products Details

Product Introduction:

MEIYUAN 1260STD ceramic fiber board is a board made by an automatic vacuum forming process. Compared with the traditional production process, we have introduced a new fully automatic production line. It can guarantee continuous work for 24 hours and dry quickly. Therefore, the ceramic fiber board has high compressive strength, neat surface, accurate size and convenient installation.

Characteristics:

Resistance to high temperature;

Low thermal conductivity;

Resistance to thermal shock;

Excellent corrosion resistance;

Low shot content ;

Low heat storage;

High compressive strength;

Good sound absorption;

Excellent wind-erosion resistance, long service life;

Excellent thermal stability and thermal shock resistance;

Easily molded or cut, easy to install;

Accurate sizes and good flatness...

Application:

Industrial heat shields & thermal barriers

Industrial combustion chamber construction

Domestic appliance & light-duty industrial combustion chamber construction

refractory lining

Molten metal trough covers

Hot gas duct linings

Expansion joints

Insulating backup to dense refractory materials

Insulating backup to brick & castable

Furnace hot face lining in ceramic kiln, box furnace & petrochemical furnace

Use in industrial heat processing equipment

Rigid high-temperature gaskets & seals

High-temperature baffles & muffles

Flue & chimney linings in furnaces & kilns

Technical data and specification

MEIYUAN ceramic fiber board
Specification temperature		1050COM	1260STD	1260 HP	1400	1430HZ
Working Temp		950℃	1050℃	1100℃	1200℃	1350℃
Color		Pure white
Permanent Linear Change on Heating(%)		≤-4	≤-3	≤-3	≤-3	≤-3
(24h,density128 kg/m3)		(950℃)	(1050℃)	(1100℃)	(1200℃)	(1350℃)
Rate of thermal conductivity(W/n.k)(Density 128 kg/m3)		0.13(600 C)	0.13(800 C)	0.13(800 C)	0.12(600C)	0.16(600C)
Rate of thermal conductivity(W/n.k)(Density 128 kg/m3)		0.20(800 C)	0.19(1000C)	0.19(1000C)	0.20(1000C)	0.20(1000C)
Chemical Composition (%)
Al2O3	37		45-46	47-49	52-55	39-40
Al2O3+SiO2	96		97	99	99	-
ZrO2	-		-	-	5	15-17
Al2O3+SiO2+ZrO2	-		-	-	-	≥99
Fe2O3	≤1.0		≤0.8	≤0.2	≤0.2	≤0.2
Na2O+K2O	≤0.8		≤0.5	≤0.2	≤0.2	≤0.2
specification
Thickness (mm)			20/25/50		80/100
Density (kg/m3)			280/300/320/350		280/300/320
Size (mm)			1200*1000 or customized size
Package			Carton box or pallet

Why choose us?

1. Self-owned raw material base, material inspection before entering the factory, computer controlled batching ratio system, strict control of raw material purity.

2. Continuously running automated production line with stable product quality, accurate dimensions and high tensile strength.

3. The automatic temperature control system can complete deep drying in 2 hours, so it has high compressive strength and high burst strength.

4. Manufacture ceramic fiber board with thickness varies from 25mm to 100mm.
